Automatic Can Briquetting Machine

Dedicated model, specially designed for the recycling and baling of metal cans, suitable for the industries which need to recycle and compress large quantities of metal cans.

  • Models specially designed for cans, featuring high efficiency, safety and reliability.
  • Available to feed manually or by conveyor.
  • PLC-controlled, fed continuously, bales come out in briquettes with reduced sizes, facilitating transportation.

Customizable colors：

Nantong Jiabao Machinery Co., Ltd.

Applicable materials

Technical Parameters

-
Model JPY-T60W JPY-T80W JPY-T100W JPY-T120W
Compression Force (Ton) 60 80 100 120
Feeding Mouth Size (L*W) mm 900*430 1000*450 1100*500 1200*550
Bale Cross-Section (WHL) mm 430*280*(150-250) 450*300*(150-250) 500*330*(200-300) 550*400*(250-350)
Power/Horsepower (Kw/Hp) 22/30 22/30 30/40 37/50
Bale Weight (Kg) 15-20 18-25 20-32 30-40
Baling Capacity (Ton/Hr) 0.5-1 0.8-1.5 1-1.8 1.5-2.5
